Commercial & Decorating lights | LUNA MCFION Lighting
CMG-TS Spotlight
Luna lighting design hotel bedroom living room wall led hat double head black white round wall lamp
Modern fashion wall lamp, wall lamp can have a very good adornment effect, make the room more stylish and bright. The material that wall lamp place uses is the high-quality goods aluminium meterail that passes factroy strictly to choose to come out.PMMA lens, CSRAM/SANAN chips optional, long lifespan, let customers use more peace of mind. style and colortemperature is optional, can use in the living room, corridor, study room, bedroom, office etc.

LN-WY-ellipse-W-01

  • Max. 7W
  • CREE CRI93
  • Beam angle 15/24/36 /60

Need more help?

Electrical
LEDs
Optical
Materials
Downloads
On request
Electrical

Power:*

7W Max

Input Voltage:

AC220-240V, or AC100-250V optional

Dimming:

On/Off, TRIAC, 0/1-10V, DALI optional

Class:

III SELV

Ambient Temperature:

0 - 40℃

Relative humidity:

<85%

LEDs

LED Brand:

San'an

LED Chip Qty:

1pcs

LED Type:

SMD

C.C.T.:

3000K, 4000K, 6000K

Color Randering Index:

>80,>90

Lumen Maintenance:

LM80

SDCM:

4

Optical

Beam Angle:

0°-45°

Luminous Flux (LED):*


Lumen Efficiency(LED):*


Luminous Flux (Luminare):*


Lumen Efficiency (Luminare):*


Materials

Body & Heatsink:

Die-casting Aluminum

Optics:

Optical PMMA

Installation:

Ceiling recessed, Thickness, Max. 25mm.

Surface Treament:

Powder-coated, Ring: sanded white

Housing Color:

Sanded white

IP Grade:

IP20

Size:

L165mm,D90mm

Cutout:


Certificates:

CE

Downloads
On request

- different power, CRI, C.C.T..

- other LED Brands, CREE, OSRAM, SAMSUNG, Bridgelux, etc.

- other Drivers, OSRAM, PHILIPS, Meanwell, KEGU, Lifud, etc.

- dimming functions: TRIAC, 0/1-10V, DALI, Mesh, 2.5G

- emergency kit with specific duration.

    LN-WY-ellipse-W-02

    • Max. 14W
    • CREE CRI93
    • Beam angle 15/24/36 /60

    Need more help?

    Electrical
    LEDs
    Optical
    Materials
    Downloads
    On request
    Electrical

    Power:*

    14W Max

    Input Voltage:

    AC220-240V, or AC100-250V optional

    Dimming:

    On/Off, TRIAC, 0/1-10V, DALI optional

    Class:

    III SELV

    Ambient Temperature:

    0 - 40℃

    Relative humidity:

    <85%

    LEDs

    LED Brand:

    San'an

    LED Chip Qty:

    1pcs

    LED Type:

    SMD

    C.C.T.:

    3000K, 4000K, 6000K

    Color Randering Index:

    >80,>90

    Lumen Maintenance:

    LM80

    SDCM:

    4

    Optical

    Beam Angle:

    0°-45°

    Luminous Flux (LED):*


    Lumen Efficiency(LED):*


    Luminous Flux (Luminare):*


    Lumen Efficiency (Luminare):*


    Materials

    Body & Heatsink:

    Die-casting Aluminum

    Optics:

    Optical PMMA

    Installation:

    Ceiling recessed, Thickness, Max. 25mm.

    Surface Treament:

    Powder-coated, Ring: sanded white

    Housing Color:

    Sanded white

    IP Grade:

    IP20

    Size:

    L165mm,D90mm

    Cutout:


    Certificates:

    CE

    Downloads
    On request

    - different power, CRI, C.C.T..

    - other LED Brands, CREE, OSRAM, SAMSUNG, Bridgelux, etc.

    - other Drivers, OSRAM, PHILIPS, Meanwell, KEGU, Lifud, etc.

    - dimming functions: TRIAC, 0/1-10V, DALI, Mesh, 2.5G

    - emergency kit with specific duration.

      In the same series

      *Due to the differences in test instruments and electronic components, the specific data may vary. Please confirm the specific parameters of the lamp before ordering to avoid misunderstanding. The luminous flux data and electrical data on the website will have  +/-10% tolerance and measured at Tc 25℃ indoors.

      *Dimensions and specifications subject to alterations without notice.
